Description
The European Double Girder Gantry Crane is a modern material handling solution designed for medium to heavy duty industrial applications. Adopting advanced European design concepts and manufacturing standards, the European Double Girder Gantry Crane offers significant advantages in terms of structural strength, operational efficiency and space utilization.
Compared with the ordinary double girder gantry crane, its main features are the use of European standards, a hardened surface of the reducer, a three-in-one drive, and PLC+frequency conversion control technology. This design comprehensively improves the product performance. At the same time, the weight of the crane is reduced by more than 15%, and the wheel pressure is reduced by 10-20%. It is suitable for general handling and lifting operations in open warehouses or along railroad tracks. It can also be equipped with a variety of lifting equipment for special operations.
Specifications
|
Differences |
European double-beam gantry crane |
Traditional double-beam gantry crane |
|
Structural weight |
Lightweight design (15-30% lighter) |
Traditional box-beam structure |
|
Operation energy consumption |
Energy saving of more than 30% |
Conventional energy consumption level |
|
Lifting height |
Height optimization and 20% improvement |
Fixed clearance requirement |
|
Control accuracy |
±1mm positioning accuracy |
±10mm conventional accuracy |
|
Maintenance cost |
Maintenance-free bearings + centralized lubrication system |
Conventional lubrication requirements |
|
Service life |
Design life of 25 years (FEM standard) |
Generally 15-20 years |
|
Ease of installation |
Generally, 15-20 years |
Large on-site welding workload |
Advantages
When purchasing a marine travel lift for sale, it is recommended to conduct a professional evaluation in the following four areas:
Lightweight & Cost-Efficient Design
Adopting advanced European FEM/DIN standards, the crane features an optimized box-girder structure that reduces overall weight by 15–30% and wheel pressure by 10–20% compared to traditional models. This lowers foundation investment and workshop construction costs while cutting energy consumption by over 30%.
High-Precision & Smooth Control
Equipped with full variable frequency drive (VFD) and PLC control, the crane enables stepless speed regulation and precise positioning with accuracy up to ±1mm. The system ensures smooth start/stop without impact, enhancing operational safety and productivity.
Optimized Lifting Height & Space Utilization
The low-headroom design and compact trolley structure increase effective lifting height by 20% and reduce hook limit dimensions. This maximizes working space, making the crane ideal for facilities with height constraints.
Long Service Life & Low Maintenance
Built with high-quality components—hardened three-in-one gear motors, forged 65Mn wheels, and maintenance-free bearings—the crane achieves a 25-year design life (FEM standard) with minimal maintenance requirements. Operating noise below 74d
Cases
